MSA Latchways Standard Self-Retracting Lifeline 30 ft 62409-00US | Galvanized Steel Fall Protection

The MSA Latchways Standard Self-Retracting Lifeline 62409-00US is engineered to deliver dependable fall protection for professionals working at height in construction, industrial maintenance, utilities, manufacturing, and energy applications.

Designed with a 30 ft (9 m) galvanized steel lifeline, this self-retracting lifeline provides excellent durability and dependable fall arrest performance for overhead anchorage systems. Unlike the stainless steel model, this version utilizes a high-strength impact-modified nylon housing, making the unit more than 50% lighter while maintaining the rugged durability required for demanding job sites.

The SRL incorporates MSA's proven Constant Force® energy absorption technology, which helps reduce fall arrest forces without relying on conventional external energy absorbers. The patented Full Contact™ positive locking mechanism ensures rapid and consistent engagement during a fall, helping minimize free-fall distance and enhancing worker safety.

The internal mechanism is constructed from stainless steel components, including the pawl, ratchet, motor spring, and chassis, providing long-term reliability and corrosion resistance. A visual-indicating steel snaphook allows for easier post-fall inspection, while the steel carabiner provides a secure connection to approved overhead anchorage points.

Supporting workers weighing 130–400 lbs (59–181 kg), including clothing and tools, the SRL is fully field-serviceable through its modular design, helping simplify maintenance and extend service life.

Certified to ANSI Z359.14, CSA Z259.2.2, OSHA, and assessed for ATEX hazardous environments, the MSA Latchways Standard Self-Retracting Lifeline is a reliable solution for demanding work-at-height applications.

Key Features & Benefits

• Part Number: 62409-00US
• 30 ft (9 m) Self-Retracting Lifeline
• 3/16 in (5 mm) Galvanized Steel Cable
• Lightweight Impact-Modified Nylon Housing
• Over 50% Lighter Than Comparable Metal Housing Models
• Constant Force® Energy Absorption Technology
• Full Contact™ Positive Locking Mechanism
• Stainless Steel Internal Components
• Aluminum Drum Assembly
• Visual-Indicating Steel Snaphook
• Steel Anchorage Carabiner
• Modular Field-Serviceable Design
• Supports 130–400 lbs (59–181 kg) Working Capacity
• Designed for Overhead Anchorage Applications
• ANSI, CSA, OSHA, and ATEX Compliant

Applications / Industries

• Construction
• Oil & Gas
• Petrochemical Plants
• Utilities
• Manufacturing
• Mining
• Renewable Energy
• Telecommunications
• Warehousing & Logistics
• Steel Fabrication
• Industrial Maintenance
• General Work at Height

Technical Specifications

Performance Features

• Rapid fall arrest using Full Contact™ locking technology
• Constant Force® energy absorption helps reduce arrest forces
• Lightweight nylon housing minimizes worker fatigue during installation and transport
• Durable galvanized steel cable provides dependable performance
• Modular construction allows convenient field servicing
• Visual load-indicating snaphook simplifies inspection after a fall event
• Corrosion-resistant internal stainless steel components
• Designed exclusively for overhead anchorage systems

What's Included

• MSA Latchways Standard Self-Retracting Lifeline (30 ft)
• Steel Carabiner
• Visual-Indicating Steel Snaphook
• User Instructions
